Technical Details

• WITH POWER CABLE
• Complies with the 802.3at PoE and the 802.3af PoE standard
• Easily merge of power and data cables into a single cable
• Extend your network to places where there are no power supply cables or sockets available no setup needed
• Supports all IEEE 802.3at-compliant PoE devices (such as access points, VoIP telephones, and IP cameras)
• Transmission range of up to 100 m – with an additional PoE extender, this can be increased to up to 400 m
• Internal consumption (full loaded): 7.0 W max.
• Input: 1x RJ-45 (data)
• Output: 1x RJ-45 (power and data)
• Data output: 100/100/1000 Mbps Gigabit
• Power output: 30 W
• Output voltage: 48 V DC
• Operating temperature range: -5 °C to +40 °C
• The output is equipped with a current limit, a short-circuit fuse and automatic terminal device recognition and classification.
