| Inherent port | 4*10/100Base-TX PoE ports (Data/Power) | 8*10/100Base-TX PoE ports (Data/Power) |
| 2*10/100Base-TX uplink RJ45 ports (Data) | 2*10/100Base-TX uplink RJ45 ports (Data) |
| PoE Port | Port 1-4 can support | Port 1-8 can support |
| EEE802.3af/at standard | IEEE802.3af/at standard |
| PoE power supply | PoE power supply |
| Functional Switch | 1*(Extender+ CCTV) |
| Note: when the switch state changes, it must be restarted before the PoE switch function can take effect |
| Network Protocol | IEEE802.3 10BASE-T; IEEE802.3i 10Base-T; |
| IEEE802.3u 100Base-TX; |
| IEEE802.3x |
| PoE Standard | IEEE802.3af/at international standard |
| Ethernet Port | Port 1-6 can support | Port 1-10 can support |
| 10/100BaseT (X) auto detect, full / half duplex MDI / MDI-X adaptive | 10/100BaseT (X) auto detect, full / half duplex MDI / MDI-X adaptive |
| Forwarding Mode | Store and forward (Full Wire Speed) |
| Switching Capacity | 1.6Gbps (Non-blocking) | 2Gbps (Non-blocking) |
| Forwarding Rate@64byte | 0.98Mpps | 1.488Mpps |
| MAC address entry | 1K |
| Buffer Memory | 768K |
| Twisted Pair
|
